Röle - PANASONIC JW2SN-DC12V POWER 5A 12VDC 2P

Röle - PANASONIC JW2SN-DC12V POWER 5A 12VDC 2P

Coil Current 44mA
Coil Resistance 270 Ohms
Rohs ROHS
Contact Form DPDT (2 Form C)
Coil Type Non Latching
Contact Current (Nom) 5A
Height 20.00mm
Packaging TRAY
Relay Type Relay Power
Coil Voltage 12VDC
Contact Voltage 250VAC/30VDC
Manufacturer PANASONIC COMP.
Series JW
Mounting Type THT
Coil Power 530mW
Operating Temperature -40°C~+60°C
Length 28.60mm
Width 12.80mm
Number of Pins 8 Pin
