Röle - HELISHUN HLS-T90(15F)-A 12V 30A Tek Kontak Röle

12V 30A T Röle HLS-T90 (15F)-A

Insulation Resistance 100M?Min at500VDC
Dielectric Strength Between Open Contacts 1500VAC 50-60HZ(1 minute)
Dielectric Strength Between Contacts And Coil 2000VAC 50-60HZ(1 minute)
Operate Time 15ms max
Release Time 10ms max
Ambient Temperature -40?to+125?
Shock Resistance Malfunction 10G
Destruction 20G
Vibration Resistance 10-55Hz,1.5mm double amplitude
Ambient humidity 40-85% RH
Weight Approx 32g
Safety Standard UL CQC
