Röle - PANASONIC JS1-B-12V-FT POWER 10A 12VDC ULTRA MINI PCB TYPE

Röle - PANASONIC JS1-B-12V-FT POWER 10A 12VDC ULTRA MINI PCB TYPE

Relay Type Relay Power
Series JS
Coil Type Non Latching
Height 16.00mm
Packaging TRAY
Manufacturer PANASONIC COMP.
Contact Form SPDT (1 Form C)
Contact Current (Nom) 6A
Coil Resistance 400 Ohms
Length 22.00mm
Width 16.00mm
Coil Current 30mA
Coil Power 360mW
Operating Temperature -40°C~+85°C
Number of Pins 5 Pin
Rohs ROHS
Mounting Type THT
Contact Current (Max) 10A
Coil Voltage 12VDC
Contact Voltage 250VAC/30VDC
